Hinged Pipe Clamps consist of a two-piece circular band connected by a hinge on one side and a single locking screw on the other, allowing the clamp to easily snap over existing pipework.

Industrial Applications: HVAC, Plumbing

Highlights: Easy Installation, Clean Aesthetic, Suitable for Retrofit Projects

Considerations: Lower Load-Bearing Capacity, Hinge Mechanism Can Wear Over Time

SPECIFICATIONS

• Materials: Galvanized Steel, Stainless Steel

• Sizes: 3/8" to 8"

• Maximum Load: 80 kg to 450 kg

• Thread & Rod Size: 3/8" to 7/8"

• Standards: MSS SP-58 (Type 12), MSS SP-69 (Type 12), Federal Spec A-A-1192A (Type 12)
